proTAC 8001A - Interference proof GNSS antenna DC-grounded, requires proGPS (N-connector)

The proTAC 8001A is a single-band, active GNSS antenna designed for reliable performance in high-interference environments. It supports GPS L1, GLONASS G1, Galileo E1, and BeiDou B1 bands, making it versatile for global navigation applications. The antenna features a dual-feed design with pre-filtering and a low noise amplifier, ensuring high signal quality by rejecting out-of-band interference. Its DC-grounded configuration provides protection against electromagnetic interference and static discharge, making it suitable for use on metallic hull vessels. The proTAC 8001A's robust construction and IP68 rating ensure it can withstand the rigors of marine environments, while its flange mount allows for easy installation on various surfaces.

GNSS Bands GPS L1, GLONASS G1, Galileo E1, BeiDou B1 Frequency range 1559 - 1606 MHz Antenna gain 28 dB typical (+/-2 dB) Noise figure 1.0 dB typical Out of band rejection < 1500 MHz: > 40 dB, < 1525 MHz: > 45 dB, > 1630 MHz: > 45 dB Connector type N-female Antenna type Single band, dual feed, pre-filtered, active GNSS antenna Supply voltage +3 to +16 V DC Current consumption 15 mA ESD protection 15 kV Polarisation RHCP Impedance 50 Ohm Height 85 mm Width 90 mm (radome) / 140 mm (base) Weight 550 g Material Plastic radome (ASA), aluminium base Mounting 140 mm flange mount IP rating IP68 with O-ring / IP66 without O-ring Wind rating 55 m/s Temperature range -40 to +85 °C Color RAL5000 Blue radome, black base
