proFIL 1010 - MF/HF Reflection Blocker 1-30MHz, 15dB attenuation

The proFIL 1010 is a coaxial cable interference filter designed for HF radios operating in the 1-30 MHz range. It minimizes interference caused by antenna circuit mismatches and cable faults, which can lead to erratic behavior in electronic systems. With a low insertion loss of less than 0.5 dB, it ensures that the original signal remains unaffected while providing over 15 dB of interference rejection. The filter's N-female connectors and 50 Ohm impedance make it compatible with standard coaxial cables, and its aluminum construction provides durability in harsh marine conditions. The proFIL 1010 complies with IEC60945 standards, ensuring reliable performance in maritime environments.

Filter type Coaxial Cable Interference Filter Passband 1-30 MHz Interference rejection > 15 dB Insertion Loss < 0.5 dB Port impedance 50 Ohm Connectors N-female Dimensions 45 mm x 165 mm x 45 mm Weight 350 g Material Aluminum body Ingress protection IP54 Operational environment -30 to +60 C Standards IEC60945
